1100P10R00 — Fireproof High Resistance Polyamide (PA) Tubing — 10mm, 100m, Clear

Description

This single layer fireproof tubing not only combines excellent resistance to pressure, temperature and flame, but also guarantees non-toxic smoke resulting from burn-off.
This tubing eliminates the need for a stripping tool, thus preventing the risk of tube damage prior to connection.
Features/Benefits:
– Safety for On-Board Railway Equipment
• Designed for on-board equipment
• Excellent flame-resistance: self-extinguishing
• Very little smoke generation
• Non-toxic combustion gases
• UV-resistant
• Extremely resistant to high pressure and temperature
– Innovative Single-Layer Solution
• Developed for demanding industrial applications
• Excellent spark resistance
• Economical alternative to PA tubing with PVC sheath
• Combines technical advantages of rigid and semi-rigid PA tubing
• 5 colours available
• Flow direction marking
• Silicone-free
Markets:
• Rail
• Miscellaneous Manufacturing
• Machine Tools
• Primary Metal Refining and Processing
Applications:
• Suitable for Fire Hazard Zones
• Air Horns
• Pneumatic Doors
• Step-Units
• Centralised Lubrication
• Welding
Technologies:
• Fireproof Tubing
• Flame Resistant Tubing
• Polyamide Tubing
• Industrial Tubing
Technical Characteristics:
• Fluids: Compressed air, lubricants, Other fluids: please consult us
• Materials: Polyamide (63 shore D)
• Pressure: Vacuum to 50 bar
• Temperature: -40°C to +100°C
Regulations:
Railway
• Pr EN 45545-2: HL3, R22, R24, R25
• NF F16101: I3 F2
• DIN 5510-2: S4, SR2, ST2
• ISO 4892
Industrial
• DI: 97/23/EC (PED)
• DI: 2002/95/EC (RoHS), 2011/65/EC
• RG: 1907/2006/EC (REACH)
• UL94 V-0 (Fire resistance)
Product Types:
• Fireproof High Resistant Polyamide
